professional factory for Self Drilling Anchor System - flange plate – Ji Luo Fastener Detail:

FLANGE STANDARD	PRESSURE RATING	TYPE	FACING	MATERIAL
ANSI B16.5	CLASS 150 300 400 600 900 1500 2500 LBS	SO WN SW TH LJ BL LWN	RF FF RTJetc	ASTM SA105/105N A350 LF2 CL1/CL2 A694 F45/52/65, s235jr C22.8;A182 F304/304L A182 F316/316L A182 F317L A182 F310 F321 F347;A182 F5 F9 F11 F51 F53 F55 F60 F304H F316H F317H, C276 INCONEL 600 625; and etc..
ANSI B16.47-A MSS	CLASS 150 300 400 600 900 LBS	WN BL
ANSI B16.47-B API	CLASS 75 150 300 400 600 900 LBS	WN BL
ANSI/ASME B16.36	CLASS 300 400 600 900 1500 2500 LBS	ORIFICE
ANSI/ASME B16.48	CLASS 150 300 400 600 900 1500 2500 LBS	FIG.8 SPACER AND BLANK SPECTACLE
AWWA C207	CLASS B & D TABLE 2/3, CLASS E TABLE 4	SO PL BL
EN 1092-1	PN 2.5 6 10 16 25 40 63 100 160 250 320 400	PL LOO BL WN SO TH
BS 4504	PN 2.5 6 10 16 25 40	PL WN TH BL SO
DIN	PN 6 10 16 25 40	PL WN TH BL LOO SO
UNI	PN 6 10 16 25 40	PL WN TH BL LOO
SABS/SANS 1123	CLASS 600 1000 1600 2500 4000 KPA	WN PL TH SO BL
JIS B2220/KS	5K 10K 16K 20K 30K 40K	SOP/PL SOH/SO BL
GOST	PN 1 1.6 2.5 4 6.3 10	PL WN BL
AS	TABLE D E F H	PL SO BL
